FAE PES Pleated Filter Cartridge For Soft Drinks
FAE series polyethersulfone (PES) membrane filter is designed to comply with all FDA requirements for food & beverage industry. The filter media is an asymmetric PES membrane that exhibits low protein-binding characteristics.
FAE series polyethersulfone (PES) membrane filter is designed to comply with all FDA requirements for food & beverage industry. The filter media is an asymmetric PES membrane that exhibits low protein-binding characteristics. FAE filter is an excellent choice as a final filter prior to bottling or storage of beverages and liquid food products.
| Dimension | |
| Outer Diameter | 69mm(2.72") |
| Length | 5”, 10”, 20”, 30”, 40” |
| Material of Constructions | |
| Media | PES |
| Support | PP |
| Cage/Core/End cap | PP |
| Connection Adaptor | SS Insert, PSU Insert |
| Seal Material Options | Silicone, EPDM , FKM |
| Operating Conditions | |
| Max. Operating Temperature | 80℃(176℉) |
| Max. Operating DP | 4 bar(58psi)@20℃(68℉),2 bar (29 psi)@80℃(176℉) |
| Sterilization | Hot water 100cycles 20 minutes at 85-90℃ |
| Filtration Area | 0.65 m² per 10” Filter |
